| Adineta sp.5, dorsoventral view, creeping; specimen from (1). |
| |
|
|
| Adineta sp.5, four aspects of the head. Upper left: Focus plane on the convex rostrum lamella, which is very wide in this species (ratio: rostrum lamella width vs. maximum head width = 0.7 to 0.85, depending on the contraction of the animal); upper right: head of fully stertched specimen. Lower left: focus plane on the rake apparatus with 5 U-hooks and 6 denticles. Lower right: specimen with folded rostral lamella. |
| |
|
| Adineta sp.5, specimen from (2) dorsoventral view, creeping. |
| |
 |
| Adineta sp.5, lateral view. |
| |
 |
| Adineta sp.5, lateral view of the head region. |
| |
 |
| Adineta sp.5, dorsoventral view showing the 8 nuclei in the vitellarium. |
| |
|
|
|
| Adineta sp.5, left image: foot of specimen from (1); right image foot of specimen from (2) |
| |
|
|
Adineta sp.5, two aspects of the rake apparatus(still image from a video); left and right rake (not the same scale! see scale bar!). |
| |
| Location: Lennetal (Hagen), wall (concrete)(1); Hattingen Oberstüter, stairs (2) |
| Habitat: dry, sunexposed moss (1); moss on concrete (2) |
| Date: 20.08.2016 (1); 03.07.2016; 07.08.2016 (2) |
